- Size: 5
- Place of Origin: CHINA
- Brand Name: Inspur
- Model Number: Inspur Yingxin I9000
- Weight: 5.000 kg
Technical Specifications
Model | NF8460M3 |
Processor | Support 4 Intel ®Xeon® processor E7-4800 v2 and E7-8800 v2 processor |
Number of cores | 6C ( E7-4809 v2 、 E7-8893 v2 ) |
8C ( E7-4820 v2 ) | |
10C ( E7-4830 v2 、 E7-8891 v2 ) | |
12C ( E7-4850 v2 、 E7-4860 v2 、 E7-8850 v2 ) | |
15C ( E7-4870 v2 、 E7-4880 v2 、 E7-4890 v2 、 E7-8870 v2 、 E7-8880 v2 、 E7-8890 v2 ) | |
Cache | 12MB ( E7-4809 v2 ) |
16MB ( E7-4820 v2 ) | |
20MB ( E7-4830 v2 ) | |
24MB ( E7-4850 v2 、 E7-8850 v2 ) | |
30MB ( E7-8857 v2 、 E7-8870 v2 、 E7-4860 v2 、 E7-4870 v2 ) | |
37.5MB ( E7-4880 v2 、 E7-4890 v2 、 E7-8880 v2 、 E7-8880L v2 、 E7-8890 v2 、 E7-8891 v2 、 E7-8893 v2 ) | |
QPI bus speed | 6.4GT/s ( E7-4809 v2 ) |
7.2GT/s ( E7-4820 v2 、 E7-4830 v2 、 E7-4850 v2 、 E7-8850 v2 ) | |
8.0GT/s ( E7-4860 v2 、 E7-4870 v2 、 E7-4880 v2 、 E7-4890 v2 、 E7-8870 v2 、 E7-8880 v2 、 E7-8890 v2 、 E7-8891 v2 、 E7-8893 v2 ) | |
Chip set | Intel ®C602 chip set |
Memory | 32 memory slots; memory can be expanded to 2TB at the maximum |
Disk controller | High-performance external SAS or SAS Raid card; support SAS 12G |
RAID | Support 1/0/10/5/50/6/60 level; support 1GB/2GB/4GB cache |
Storage | Support 16 2.5” hot-plug SAS/SATA/SSD disks at the maximum |
I/O expansion slot | Motherboard provided with eight PCI-E 3.0 slots (two interior full-height full-length x8 PCI-E, two full-height and full-length x16 PCI-E and four full-height and full-length x16 PCI-E; all are full-bandwidth slots) |
Via PCIE expansion cards, it can be expanded to the following at the maximum in the chassis dimensions | |
10 PCI-E 3.0 slots | |
2 full-height half-length x4 PCI-E, 3 full-height half-length x8 PCI-E (two interior), 2 full-height half-length x16 PCI-E and 3 full-height full-length x16 PCI-E | |
12 PCI-E 3.0 slots | |
4 full-height half-length x4 PCI-E, 4 full-height half-length x8 PCI-E (two interior), 1 full-height half-length x16 PCI-E and 3 full-height full-length x16 PCI-E | |
Integrated I/O port | 前置: 2 个 USB 接口, 1 个 VGA 接口 Front installation: 2 USB interfaces and 1 VGA interface |
Back installation: four RJ45 interfaces; one RJ45 1G administration network interface; one VGA interface; four USB 2.0 interfaces and one serial port | |
Network controller | Integrated with 4 high-performance 1G network interface (2 Intel I350 network chips) |
Support network awakening, network redundancy, load balancing and other advanced network features | |
Power supply | Support four 700W platinum-level high-efficiency hot-plug power module at the maximum; optional 2+1, 2+2 or 3+1 redundancy mode |
Graphical card | Integrated with a display controler with a 16MB graphical memory (AST2300) |
DVD drive | Optional standard DVD drive |
Floppy disk drive | Virtual floppy disk drive with USB interface as the standard configuration |
Management | Support Inspur Ruijie administration set; adopt Inspur advanced server administration module; promote remote administration and diagnosis features; support IPMI1.5, IPMI2.0, WfM2.0, EMP and KVM over IP |
Supported operating systems | Microsoft Windows 2012 Enterprise 64bit |
Redhat Linux Enterprise server 6.4 64bit | |
Suse Linux 11 Enterprise server SP3 32bit/64bit | |
VMware ESXi 5.1 | |
Different operating systems are supported in different configurations. Consult with Inspur for details. | |
Working environmental temperature | 5 ℃ ~ 35 ℃ |
Mains voltage | 100-240V |
International certification | ISO9000 international quality management system |
ISO14001 international environment management system | |
Chassis dimensions | 174.8mm (H), 447.6mm (W) and 749mm (D) |
Reference weight | 42kg |
- Size: 5
- Place of Origin: CHINA
- Brand Name: Inspur
- Model Number: Inspur Yingxin I9000
- Weight: 5.000 kg
